Liquid Force 2024 Carbon Horizon Foil Surf Sets - with Size 190 Front Wing
CARBON HORIZON SURF 190 - Ideal for ANY boat and hijacking waves, the 190 keeps fun and stability high!
Elevate your wakeboarding experience with the 2024 Carbon Horizon 190 Foil Set, perfect for all skill levels!
The Horizon 190 offers our biggest surface area wing meaning you need less of a wave or roller to have a good time. Don’t have a surf boat? Have a small fishing boat? The 190 has you covered! The 3k prepreg carbon fibre has a huge weight to strength ratio and doesn’t use unnecessary additional resin keeping it light and responsive. With LF's highest stability in a wing, the Horizon is great for inspiring confidence when starting out.
This medium aspect wing for is for all levels and abilities. With a low speed lift, these foils are geared to excel within all conditions found on the lake. They are optimized for wakesurf boat speed and,depending on the size, can be foiled on everything from a jet ski to large fast wakes.
This 190 front wing is great for little wakes, and big units. If you're 100+ kilos then grab this one. If your boat wake is a jet ski, then grab this one. But it also works as a foil that can pump and glide and make turns for most people making it also a decent foil to learn on.
Features of 190:-
- Horizon 190 Front Wing - Surface Area 1900 cm² | 100 cm Wingspan
- H24 Rear Stabilizer Wing - Surface Area 240 cm² | 37 cm Wingspan
- 28" Carbon Mast
- 44cm Short Fuselage
- Foil Shim Kit Included
- Carrying Case
- (28" Carbon Mast + 190 wing + H24 STAB + 44 Fuse)
Aspects of Foil Technology and Terminology
Stability can be thought of as the ability to recover with minimal effort. Highly stable foils will allow you to make mistakes and get off balance but wont effect your ride or ability to maintain lift. These foils are not as agile or nimble and can not be turned as hard or used as aggressively. The Horizon 190 and 155 would fall into this category. At the other end you will find the Glider 95 which is highly maneuverable, but you need to be a bit more on you’re A game to harness the magic.
Good pumping foils give good glide and enough lift with minimal effort put in by the rider. With every physical movement expended by the rider, the foil needs to translate that into speed and forward movement. Bigger foils can go slower and are easy to get going at the begging. The Horizon 190 is a great foil for dock starts and starting from zero. The Glider series needs speed to start but once you are going, it is much easier to maintain momentum.
- High Aspect = High Speed
- Medium Aspect = Medium Speed
The speed can be directly related to the efficiency of the wing. The High Aspect Wings have lower drag and therefore are able to reach higher speeds. By the same token, size affects the speed as well. Smaller wings can go faster due to the lower drag.
Area is the first indicator of how the foil will perform. Larger area wings are made for going slower and accommodating heavier riders. Smaller wings will be faster. Area is not an indicator of skill level. Smaller wings will be used by both novice and advanced riders. Advanced riders will gravitate towards smaller wings due to the increase in speed that is possible. Novice riders will also gravitate towards smaller wings as the lift of the smaller wings is less and more manageable for the first time rider.
Wingspan, defined as the tip to tip distance of a foil. The Wingspan primarily controls a foils ability to roil. The shorter the wingspan the easier it is to roll the wing over and get a high banking turn. The Wingspan also effects the drag and overall speed of the wing. For a wing of a given area and lift profile, extending the wingspan allows you to shorten the chord length while keeping a similar amount of lift. This usually equates to lower drag and a higher speed foil.
Defined as the wingspan ^2 divided by the wing area (B^2/S), the aspect ratio is the defining term for the efficiency of a foil. Typically speaking , the higher the aspect the more efficient the foil is. This leads to longer glides and higher speeds. The higher aspect wings have a higher level of required skill to ride and are not as forgiving as a medium aspect wing. Most beginner to intermediate riders will gravitate towards a medium aspect foil (3-6) due to the ability to achieve lift at lower speeds and bigger sweet spot that allows for easy recoveries while foiling. Advanced riders will gravitate towards a high aspect roil (7-10) as the overall speed the foil can go and generate is much higher. This leads to more progressive foiling.
Foils can be ridden in just about any conditions. That is the beauty of it. Foils allow the previously unrideable to be ridden and give new life to the status quo. Within the seemingly endless variety of conditions that occur, there are designs that are better suited for the conditions. Bigger waves will require smaller faster foils while smaller waves need bigger foils. The Horizon line (Medium-Aspect) covers pretty much all conditions you will find yourself in a lake. The 190 will work for jetskis and direct drives. The 155 will work on any watercraft that can tow you. The 120 will be best suited for your traditional surf/wake boat. The Glider line (High Aspect) will take you even further. The 115 works great for your surf/wake boat and the 95 while also working in those conditions will get you out into the ocean surf as your foiling expands into new realms.
FLIGHT WING TECH:-
WHIPS & PUMPS
